UL-Certified Phosphorus FR ABS Resin: Non-Halogen Safety for High-Temperature Environments
Different generations’ typical properties of thermal conductive PA
| Properties | Test Method | Test Condition | Unit | Typical Values(dry) |
| Physical properties | ||||
| Specific Gravity | ISO 1183 | 23°C | g/cm³ | 1.56 |
| Ash | ISO 3451 | 800°C,30min | % | 50 |
| Mechanical properties | ||||
| Tensile Strength | ISO 527 | 5mm/min | MPa | 210 |
| Tensile Modulus | ISO 527 | 1mm/min | MPa | 15000 |
| Elongation at Break | ISO 527 | 5mm/min | % | 2 |
| Flexural Strength | ISO 178 | 2mm/min | MPa | 350 |
| Flexural Modulus | ISO 178 | 2mm/min | MPa | 14000 |
| Unotched Charpy Impact Strength | ISO 179-1/1eU | 23°C | kJ/m2 | 100 |
| Notched Charpy Impact Strength | ISO 179-1/1eA | 23°C | kJ/m2 | 17 |
| Thermal properties | ||||
| Heat deflection temperature | ISO 75 | 1.80MPa | °C | 215 |
| Melt Temperature | ISO 11357 | DSC | °C | 220 |
| Other properties | ||||
| Mold Shrinkage | internal test method | flow direction | % | 0.10-0.20 |
| cross flow direction | % | 0.60-0.80 | ||
| Flammability | ISO 3795 | - | mm/min | 30 |
Production Description
Advanced PA6 formulations combine Nylon 6’s inherent strength with nanotechnology enhancements. Carbon nanotube additives (2-5% wt.) improve EMI shielding (40dB attenuation) while maintaining 120MPa tensile strength – critical for drone propellers and 5G antenna enclosures demanding conductivity and lightness.
Retains PA6’s inherent benefits (high strength, abrasion resistance) while addressing weaknesses like moisture sensitivity or brittleness.
Competes with metals and more expensive polymers (e.g., PEEK) in high-stress applications.
Cost-effective for mass production due to improved processing and performance.
Thermally Conductive PA Product Application
